Technology

Recover the energy you've already paid for.

Tight homes need balanced ventilation. Ventiq's enthalpy cores transfer heat and humidity between exhaust and intake airstreams — so fresh outdoor air arrives pre-conditioned.

Cross-flow enthalpy core diagram
Enthalpy Core

A quiet exchange of heat and moisture.

Inside every Ventiq ERV, two airstreams flow past each other through a cross-flow exchanger. Energy and water vapor migrate from the warmer, more humid stream to the cooler, drier one — without the streams ever mixing.

  • Summer: incoming hot, humid air is pre-cooled and dehumidified by the conditioned exhaust.
  • Winter: outgoing warm room air pre-heats and humidifies the cold, dry intake.
Up to 84%
Apparent effectiveness

Measured per CSA C439 at standard cooling conditions.

0.4 in. w.g.
External static pressure

Rated airflow at residential duct system pressures.

−18 °F
Cold-climate ready

Recirculation defrost protects the core in deep cold.
